Τιμή

N/A

Δύναμη

8.5kW at 7500 r/min

Μέγιστη Ροπή

12.0N·m/5500 r/min

βάρος οχηματος

128

Τεχνικές Προδιαγραφές

  • Bore x Stroke (mm)

    ø61.5×57.8

    Displacement (cc)

    171.7

    Type

    1-cylinder/4-stroke/2-valve

    Power

    8.5kW at 7500 r/min

    Max. torque

    12.0N·m/5500 r/min

    Compression ratio

    9.75±0.2:1

    Fuel system

    Carburetor & EFI

    Valve train

    SOHC

    Ignition

    TCI

    Starter

    Electric & Kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Forced-air-cooled

  • Final drive

    Belt

    Clutch type

    Automatic

  • Front wheel

    Alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    75

    Front tyre

    110/70-13

    Rear wheel

    Alloy

    Rear suspension

    Dual shock-absorber

    Rear suspension travel (mm)

    50

    Rear tyre

    130/70-13

    Front brakes

    Disc

    Front brakes diameter (mm)

    240

    Rear brakes

    Disc

    Rear brakes diameter (mm)

    215

  • Dry weight (kg)

    128

    Seat height (mm)

    770

    Overall length (mm)

    1930

    Overall width (mm)

    755

    Overall height (mm)

    1130

    Ground clearance (mm)

    135

    Wheelbase (mm)

    1385

    Fuel capacity (L)

    9.5

    Top speed (km/h)

    95

    Max. load (kg)

    160

    Battery

    12V8Ah
